there are examples of drawing:
see Continuous Lines / Examples / Processing.org
or here where you can switch between drawing cirlce / line
// draw program
// rubber = rubber
PFont font;
//PShape ellipse;
color currentFill=color(111);
ArrayList<Button> buttons = new ArrayList();
boolean hold=false;
// define modes
final int lineMode = 0;
final int circleMode = 1;
final int rubberMode = 2;
//current mode
int mode = lineMode;
// names of modes
String[] stringMode={ "line",
"circle (drag mouse)",
"rubber"};
// draw a circle variables
boolean drawNewCircle; // During mouse dragging we can still abort the circle with ESC and change its size with the mouse
PVector startCircle=new PVector();
float diameter;
void setup() {
size(768, 1024);
PImage rubber;
PImage save;
PImage delete;
PImage circle;
background(255);
rubber = loadImage("gomme.png");
save = loadImage("save.png");
delete = loadImage("delete.png");
circle = loadImage("circle.png");
//ellipse = loadShape("ellipse.svg");
// font = loadFont("Grotex-Regular-48.vlw");
// textFont(font);
defineButton(rubber, "rubber", 600, 20, 64, 74);
defineButton(save, "save", 520, 20, 64, 74);
defineButton(delete, "delete", 680, 20, 64, 74);
//shape(ellipse, 300, 380, 188, 188);
defineButton(circle, "circle (on/off)", 400, 20, 188, 188);
}
void draw() {
helpTextUpperLeftCorner();
// display buttons
for (Button b : buttons) {
b.display();
}
textSize(48);
text("un soleil", 20, 60);
fill(210);
stroke(0);
strokeWeight(6);
if (!hold) {
switch(mode) {
case circleMode:
// ignore
break;
case lineMode:
if (mousePressed) {
line(mouseX, mouseY, pmouseX, pmouseY);
}
break;
case rubberMode:
//
if (mousePressed) {
fill(255);
noStroke();
rect(mouseX, mouseY, 3, 3);
}
break;
default:
//Error
break;
}//switch
}//if
// During mouse dragging we can still abort the circle with ESC and change its size with the mouse
if (drawNewCircle) {
// delete old circle
stroke(255);
fill(255);
strokeWeight(3);
ellipse( startCircle.x, startCircle.y, diameter, diameter);
// show circle with current size diameter
stroke(0);
noFill();
strokeWeight(1);
diameter = 2 * dist (mouseX, mouseY,
startCircle.x, startCircle.y);
stroke(0);
ellipse( startCircle.x, startCircle.y, diameter, diameter);
}//if
//
}
// -----------------------------------------------------
void helpTextUpperLeftCorner() {
//
textAlign(LEFT);
fill(255);
noStroke();
rect(0, 0, width, 30);
fill(0);
textSize(17);
if (drawNewCircle) {
text("drag mouse to resize circle, ESC to abort", 22, 22);
} else {
text("mode is " + stringMode[mode], 22, 22);
}//else
// default
fill(210);
}//func
void mousePressed() {
for (Button b : buttons) {
if (b.over()) {
exec(b.id);
hold=true;
return;
}//if
}//for
if (mode==circleMode) {
startCircle.x=mouseX;
startCircle.y=mouseY;
drawNewCircle=true;
diameter=0;
}
}
void mouseReleased() {
if (drawNewCircle) {
// finish the circle in red
noStroke();
fill(currentFill);
ellipse( startCircle.x, startCircle.y, diameter, diameter);
}
hold=false;
drawNewCircle=false;
diameter=0;
}
// ------------------------------------------------------------
void keyPressed() {
if (key==ESC) {
key=0;
if (drawNewCircle) {
stroke(255);
fill(255);
strokeWeight(3);
ellipse( startCircle.x, startCircle.y, diameter, diameter);
hold=false;
drawNewCircle=false;
diameter=0;
}
}
// COLORS
else if (key=='0') {
currentFill=color(255, 0, 0);
} else if (key=='1') {
currentFill=color(0, 255, 0);
} else if (key=='2') {
currentFill=color(0, 0, 255);
} else if (key=='3') {
currentFill=color(0);
} else if (key=='4') {
currentFill=color(201);
} else if (key=='5') {
currentFill=color(34);
} else if (key=='6') {
currentFill=color(255, 248, 44);
}
}
// -------------------------------------------------------------------
void exec(int id) {
// execute commands
println(id);
switch (id) {
case 0:
mode=rubberMode;
break;
case 1:
//
save("zrewuizwre.png");
break;
case 2:
background(255);
break;
case 3:
if (mode!=circleMode)
mode=circleMode;
else
mode=lineMode;
break;
default:
break;
}//switch
}
void defineButton(PImage img,
String s,
float x, float y,
float w, float h) {
buttons.add (new Button(img, s, x, y, buttons.size()));
}
//===================================================================
class Button {
PImage img=null;
String s;
float x, y;
int id;
Button(PImage img_,
String s_,
float x_, float y_,
int id_) {
img=img_;
s=s_;
x=x_;
y=y_;
id=id_;
}
void display() {
if (img!=null) {
imageMode(CENTER);
image(img, x, y);
return;
}
textAlign(CENTER);
textSize(17);
text(s, x, y);
textAlign(LEFT);
}//
boolean over() {
return
dist (mouseX, mouseY, x, y) < 30;
}
//
}//class
//
