OK, i’m making flappy birds using notepad ++ javascript.
I was following along with this tutorial after adding the files from his neural network videos and when he tested his program mine didn’t work. I checked the error and it pointed to bird.7 or however that error writes it. I checked the line and saw it was written the same as how the video has it. I cant figure out whats wrong with my program and why it not doing the same as in the video.
here sketch
var bird;
var pipes = [];
var score = 0;
function setup(){
createCanvas(400,600);
bird = new Bird();
pipes.push(new Pipe());
}
function draw(){
background(0);
bird.think();
bird.show();
bird.move();
text(score,10,10);
if (frameCount % 300 == 0){
pipes.push(new Pipe());
}
for (var i = pipes.length-1; i >= 0; i--){
pipes[i].show();
pipes[i].update();
if (pipes[i].x < -pipes[i].w){
pipes.splice(i,1);
score += 1;
}
if (pipes[i].hits(bird)){
console.log("Collide");
}
}
}
here bird
function Bird(){
this.y = height/2;
this.x = 50;
this.grav = 0.6;
this.vel = 0;
this.lift = -15;
this.brain = new NeuralNetwork(4,4,1);// here where it say error
this.show = function() {
fill(255);
ellipse(this.x,this.y,32,32);
}
this.up = function(){
this.vel += this.lift;
}
think() = function(){
let input = [1.0,0.5,0.2,0.3];
let output = this.brain.predict(inputs);
if (output > 0.5){
this.up();
}
}
this.move = function(){
this.vel += this.grav;
this.vel *= 0.9;
this.y += this.vel;
if (this.y > height) {
this.y = height;
this.vel = 0;
}
if (this.y < 0) {
this.y = 0;
this.vel = 0;
}
}
}
here pipes
function Pipe() {
var spacing = 75;
var centery = random(spacing,height-spacing);
this.top = centery - spacing/2;
this.bottom = height - (centery + spacing/2);
this.x = width;
this.w = 20;
this.speed = 1;
this.c = 0;
this.highlight = false;
this.hits = function(bird){
if (bird.y < this.top || bird.y > height - this.bottom){
if (bird.x > this.x && bird.x < this.x + this.w){
this.highlight = true;
return true;
}
}
this.highlight = false;
return false;
}
this.show = function(){
fill(255);
if (this.highlight){
fill(255,0,0);
}
rect(this.x, 0, this.w, this.top);
rect(this.x, height-this.bottom, this.w, this.bottom);
}
this.update = function(){
this.x -= this.speed;
}
}
here nn
class ActivationFunction {
constructor(func, dfunc) {
this.func = func;
this.dfunc = dfunc;
}
}
let sigmoid = new ActivationFunction(
x => 1 / (1 + Math.exp(-x)),
y => y * (1 - y)
);
let tanh = new ActivationFunction(
x => Math.tanh(x),
y => 1 - (y * y)
);
class NeuralNetwork {
// TODO: document what a, b, c are
constructor(a, b, c) {
if (a instanceof NeuralNetwork) {
this.input_nodes = a.input_nodes;
this.hidden_nodes = a.hidden_nodes;
this.output_nodes = a.output_nodes;
this.weights_ih = a.weights_ih.copy();
this.weights_ho = a.weights_ho.copy();
this.bias_h = a.bias_h.copy();
this.bias_o = a.bias_o.copy();
} else {
this.input_nodes = a;
this.hidden_nodes = b;
this.output_nodes = c;
this.weights_ih = new Matrix(this.hidden_nodes, this.input_nodes);
this.weights_ho = new Matrix(this.output_nodes, this.hidden_nodes);
this.weights_ih.randomize();
this.weights_ho.randomize();
this.bias_h = new Matrix(this.hidden_nodes, 1);
this.bias_o = new Matrix(this.output_nodes, 1);
this.bias_h.randomize();
this.bias_o.randomize();
}
// TODO: copy these as well
this.setLearningRate();
this.setActivationFunction();
}
predict(input_array) {
// Generating the Hidden Outputs
let inputs = Matrix.fromArray(input_array);
let hidden = Matrix.multiply(this.weights_ih, inputs);
hidden.add(this.bias_h);
// activation function!
hidden.map(this.activation_function.func);
// Generating the output's output!
let output = Matrix.multiply(this.weights_ho, hidden);
output.add(this.bias_o);
output.map(this.activation_function.func);
// Sending back to the caller!
return output.toArray();
}
setLearningRate(learning_rate = 0.1) {
this.learning_rate = learning_rate;
}
setActivationFunction(func = sigmoid) {
this.activation_function = func;
}
train(input_array, target_array) {
// Generating the Hidden Outputs
let inputs = Matrix.fromArray(input_array);
let hidden = Matrix.multiply(this.weights_ih, inputs);
hidden.add(this.bias_h);
// activation function!
hidden.map(this.activation_function.func);
// Generating the output's output!
let outputs = Matrix.multiply(this.weights_ho, hidden);
outputs.add(this.bias_o);
outputs.map(this.activation_function.func);
// Convert array to matrix object
let targets = Matrix.fromArray(target_array);
// Calculate the error
// ERROR = TARGETS - OUTPUTS
let output_errors = Matrix.subtract(targets, outputs);
// let gradient = outputs * (1 - outputs);
// Calculate gradient
let gradients = Matrix.map(outputs, this.activation_function.dfunc);
gradients.multiply(output_errors);
gradients.multiply(this.learning_rate);
// Calculate deltas
let hidden_T = Matrix.transpose(hidden);
let weight_ho_deltas = Matrix.multiply(gradients, hidden_T);
// Adjust the weights by deltas
this.weights_ho.add(weight_ho_deltas);
// Adjust the bias by its deltas (which is just the gradients)
this.bias_o.add(gradients);
// Calculate the hidden layer errors
let who_t = Matrix.transpose(this.weights_ho);
let hidden_errors = Matrix.multiply(who_t, output_errors);
// Calculate hidden gradient
let hidden_gradient = Matrix.map(hidden, this.activation_function.dfunc);
hidden_gradient.multiply(hidden_errors);
hidden_gradient.multiply(this.learning_rate);
// Calcuate input->hidden deltas
let inputs_T = Matrix.transpose(inputs);
let weight_ih_deltas = Matrix.multiply(hidden_gradient, inputs_T);
this.weights_ih.add(weight_ih_deltas);
// Adjust the bias by its deltas (which is just the gradients)
this.bias_h.add(hidden_gradient);
// outputs.print();
// targets.print();
// error.print();
}
serialize() {
return JSON.stringify(this);
}
static deserialize(data) {
if (typeof data == 'string') {
data = JSON.parse(data);
}
let nn = new NeuralNetwork(data.input_nodes, data.hidden_nodes, data.output_nodes);
nn.weights_ih = Matrix.deserialize(data.weights_ih);
nn.weights_ho = Matrix.deserialize(data.weights_ho);
nn.bias_h = Matrix.deserialize(data.bias_h);
nn.bias_o = Matrix.deserialize(data.bias_o);
nn.learning_rate = data.learning_rate;
return nn;
}
// Adding function for neuro-evolution
copy() {
return new NeuralNetwork(this);
}
// Accept an arbitrary function for mutation
mutate(func) {
this.weights_ih.map(func);
this.weights_ho.map(func);
this.bias_h.map(func);
this.bias_o.map(func);
}
}
here matrix
class Matrix {
constructor(rows, cols) {
this.rows = rows;
this.cols = cols;
this.data = Array(this.rows).fill().map(() => Array(this.cols).fill(0));
}
copy() {
let m = new Matrix(this.rows, this.cols);
for (let i = 0; i < this.rows; i++) {
for (let j = 0; j < this.cols; j++) {
m.data[i][j] = this.data[i][j];
}
}
return m;
}
static fromArray(arr) {
return new Matrix(arr.length, 1).map((e, i) => arr[i]);
}
static subtract(a, b) {
if (a.rows !== b.rows || a.cols !== b.cols) {
console.log('Columns and Rows of A must match Columns and Rows of B.');
return;
}
// Return a new Matrix a-b
return new Matrix(a.rows, a.cols)
.map((_, i, j) => a.data[i][j] - b.data[i][j]);
}
toArray() {
let arr = [];
for (let i = 0; i < this.rows; i++) {
for (let j = 0; j < this.cols; j++) {
arr.push(this.data[i][j]);
}
}
return arr;
}
randomize() {
return this.map(e => Math.random() * 2 - 1);
}
add(n) {
if (n instanceof Matrix) {
if (this.rows !== n.rows || this.cols !== n.cols) {
console.log('Columns and Rows of A must match Columns and Rows of B.');
return;
}
return this.map((e, i, j) => e + n.data[i][j]);
} else {
return this.map(e => e + n);
}
}
static transpose(matrix) {
return new Matrix(matrix.cols, matrix.rows)
.map((_, i, j) => matrix.data[j][i]);
}
static multiply(a, b) {
// Matrix product
if (a.cols !== b.rows) {
console.log('Columns of A must match rows of B.')
return;
}
return new Matrix(a.rows, b.cols)
.map((e, i, j) => {
// Dot product of values in col
let sum = 0;
for (let k = 0; k < a.cols; k++) {
sum += a.data[i][k] * b.data[k][j];
}
return sum;
});
}
multiply(n) {
if (n instanceof Matrix) {
if (this.rows !== n.rows || this.cols !== n.cols) {
console.log('Columns and Rows of A must match Columns and Rows of B.');
return;
}
// hadamard product
return this.map((e, i, j) => e * n.data[i][j]);
} else {
// Scalar product
return this.map(e => e * n);
}
}
map(func) {
// Apply a function to every element of matrix
for (let i = 0; i < this.rows; i++) {
for (let j = 0; j < this.cols; j++) {
let val = this.data[i][j];
this.data[i][j] = func(val, i, j);
}
}
return this;
}
static map(matrix, func) {
// Apply a function to every element of matrix
return new Matrix(matrix.rows, matrix.cols)
.map((e, i, j) => func(matrix.data[i][j], i, j));
}
print() {
console.table(this.data);
return this;
}
serialize() {
return JSON.stringify(this);
}
static deserialize(data) {
if (typeof data == 'string') {
data = JSON.parse(data);
}
let matrix = new Matrix(data.rows, data.cols);
matrix.data = data.data;
return matrix;
}
}
if (typeof module !== 'undefined') {
module.exports = Matrix;
}
so in conclusion his code at this stage sends the bird up or down. mine gives me an error.
